Fiberglass multiaxial fabrics is a non-crimped, multi-axial and multi-layered reinforcement material.

Product Details

Fiberglass multiaxial fabrics is a non-crimped, multi-axial and multi-layered reinforcement material. The number of layers, axial direction, grammage, and specific fiber weight of each layer vary depending on the application itself. Each layer is stitched with polyester yarn. Such fabrics can be manufactured by using different combinations of directions (0°, 90°, +45°, -45°), or by stitching with non-woven materials such as chopped fibers or thin mats.

Product Parameters

Product No.Overall
Density
(g/m2)
0° Roving
Density
(g/m2)
+45° Roving
Density
(g/m2)
90° Roving
Density (g/m2)
-45°Roving
Density
(g/m2)
Polyester
Yarn Density
(g/m2)
QX-E600601.4144.7150.4150150.46
QX-E800823.8216200.5200.8200.56
QX-E10009542162482362486
QX-E11501178.7294300.6283.5300.66
QX-E12001201.2294300.63o0300.67
QX-E160016204343085643087


Solution to Markets

It is used for such products include wind energy, marine/shipbuilding, fiberglass moulds, pultruded profiles, automotive, aerospace, defense, and more.


Produce & Shipment

  • -1_0003_IMG20190322094846
  • -1_0003_IMG20190321154725
  • -1_0007_微信图片_202010131205193
  • -1_0003_IMG_1757
  • -1_0000_IMG20190412142629
  • -1_0007_b77096e58478b1b2d492f42e02932e1 (2)

Exhibition Display

  • -1_0035_eaf1dd271f7d27a1c6c40ec7106d418
  • -1_0023_IMG_20190517_123321
  • -1_0000_微信图片_20230508152045
  • -1_0005_IMG20190314113411
  • -1_0017_IMG_20190518_153451
