◎ Uniform tension, warp and weft yarn even and flat ;
◎ Fiber arrayed in high density, easily deformed and operation;
◎ Good moldability, fast and wet out completely in resins.
◎ 2 layers fabrics combined improves higher productivity.
E-Glass Fiberglass Woven Roving Combo Mat is a layer of fiberglass woven roving composed with a layer of staple chopped fiberglass strand randomly dispersed and stitched togther by polyester yarn.
Specification | Density gsm | woven roving | Deviation % | CSM | Stitched Yarn | ||||
weight | g/㎡ | weight | g/㎡ | weight | g/㎡ | ||||
ERM300/300 | 610 | 300 | ±7 | 300 | 10 | ||||
ERM500/300 | 810 | 500 | 300 | 10 | |||||
ERM500/450 | 960 | 500 | 450 | 10 | |||||
ERM600/300 | 910 | 600 | 300 | 10 | |||||
ERM600/450 | 1060 | 600 | 450 | 10 | |||||
ERM800/300 | 1110 | 800 | 300 | 10 | |||||
Special specifications could be customized. |
Mainly used for production of winding, pultrusion, RTM and hand layup processing etc.
☆ Combined to resin for composites, like GRP pipe, tank;
☆ GRP containers and automotive parts;
☆ Boat and car body.
